WE-MP80 MULTI-PACKMACHINE-ZLINK TECHNOLOGIES (ZHENGZHOU) CO. LTD.

MACHINE FEATURES & HIGHLIGHTS

Designed with advanced automation, the machine utilizes a sophisticated robotic arm to seamlessly open packaging bags. The integrated detection system ensures that any bags not properly opened are automatically rejected, maintaining uninterrupted and stable operation. This innovative feature guarantees the highest standards of reliability and product integrity. Perfectly suited for supermarket promotions, the WE-MP80 packages between 2 to 6 packs of wet wipes per bundle, making it an ideal solution for multi-pack promotional offerings. Its ergonomic design and functionality significantly enhance user convenience and reduce packaging costs. With its cutting-edge automation and precise detection technology, the WE-MP80 wet wipes multi-pack machine delivers superior performance, ensuring that your products meet market demands with unmatched efficiency and quality.

Electrical system
The electrical system features a safety circuit design compliant with CE safety standards, ensuring safe and reliable operation.
Control system
The machine utilizes the Mitsubishi Q series motion control PLC, with all mechanical motion control axes powered by servo motors for precise and efficient performance.
HMI (Human-Machine Interface)
Equipped with a Mitsubishi 8” color LCD touch screen with a resolution of 640*480, the HMI communicates via Ethernet, providing a user-friendly and high-resolution interface.
Twisting conveyor
The twisting conveyor allows changing product orientation to meet specific packaging requirements.
Stacker
The stacker includes an automatic rejection system, ensuring stable and continuous operation by removing any faulty products from the line.
Rotary bag opener
This feature automatically detects and rejects products that are not properly bagged, preventing sealing and cutting errors associated with unbagged products.
Automatic bag opening
A robotic arm automatically opens the packaging bag and detects if the bag is not opened properly, automatically rejecting any unopened bags to maintain product quality and consistency.
Equipment Self-Healing function
The equipment is equipped with a self-inspection system that automatically eliminates certain faults without halting the machine, ensuring uninterrupted and smooth operation.

TECHNICAL DATA

Preformed Bag Specifications:Length: 320-400mm Width: 150-200mm Height: 110mm (excluding the hanging die-hole part)
Packing Specifications:Multipack Options: 3, 4, 5, or 6 packs per multipack Single Pack Height: 35-80mm
Production Speed:35 multipacks per minute
Occupied Area:Length: 5300mm Width: 6300mm Height: 2400mm
Power Requirements:Rated Power: 15KW Voltage: AC 380V (customizable) Frequency: 50/60HZ Configuration: Three-phase, five-wire system
Compressed Air Requirements:Pressure: 0.6-0.8Mpa Consumption: 200L/min
Machine Weight:Net Weight: Approximately 3500 KGS
