WE-BM60 MULTI-PACKMACHINE-ZLINK TECHNOLOGIES (ZHENGZHOU) CO. LTD.

MACHINE FEATURES & HIGHLIGHTS

Electrical system
Electrical safety circuit design and comply with CE safety standard
Control system
Using Mitsubishi Q series motion control type PLC controling, and mechanical motion controlaxes are all servo-controlled
HMI
Mitsubishi 8”color LCD touch screen: resolution 640*480, communication mode Ethernet
wet wipes twisting module
Wet wipes package direction can be set
Stacking module
Auto reject excess products and ensure machine stable operation
Feeding robot arm
Wet wipes package quantity settable
bag turning opener device
Auto reject empty bag to prevent the empty bag or no bag sealing
Auto bag opening
Bag is automatically opened by the robot arm and automaticallydetects that the bag is not open and reject not opened bags

Trimming collectionTrimming is automatically collected to the waste bin on-line without machine stop
Self-adapting debugSelf-adapting debug system nonstop machine resolve some of faults automaticall
Code printer(OptionalOn-line date code print
SCADA application program(options)(Supervisory Control And Data Acquisition) equipment operating and detection data output port
Applicable raw materialsPVC, Pl, synthetic paper
Label SpecificationsL100-380mm,W150-240mm, H80-150mm
Packing specifications90 single bags/min or 40 multipack/min, whichever comes first
Designed speed45 multipacks/min
External dimensionL3900mm, w1850mm, H1900mm
Rated powerAC380V(Customizable), 50/60Hz,three-phase five-wire, 15kW
Compressed air0.6-0.8Mpa, 200L/min
Net weightAbout 2500KGS
